HS-PV9000-48 P
HS-PV9000-48 P
HS-PV9000-48 P

HS-PV9000-48 P

Our HS-PV9000-48 P 48V 9kW low-frequency inverter features solid pure copper coils for heavy loads. High-performance MPPT boosts solar harvesting efficiency. Multi-level safety safeguards stable operation, an ideal power supply for workshops, remote shops and commercial emergency power.

Sales Count Click

Sales Count

Click

HS-PV9000-48 P

Select the number of specifications

Please check the product information you want!

Product Detail

SINGLE PHASE HYBRID GRID INVERTER


AC Input
Rated Input Voltage (VAC)208/220/230/240;L +N+PE
Voltage Range (VAC)90~280+3 (APP/GEN mode); 170~264 (UPS mode)
Frequency (Hz)50/60 (Auto Adaptive)
AC Output
Rated Capacity (kVA/kW)6.5 (Output Power rating will be reduced to 90%,when setting the Output Voltage to 208V.OutputPower rating will be reduced to 95% in parallel mode.)
Surge Power (kVA)12
Voltage (VAC)208/220/230/240
Power Factor (PF)1
Frequency50/60Hz+0.1%
Switch Time (ms)10(APP/GEN mode)/20 (GEN mode)
Wave FormPure Sine Wave
Overload Capacity

1min@102%-125% load;10s@>120% load

Max. Efciency (Batter Mode)94%@48VDC
Charger (PV/AC)
Solar Charger TypeMPPT
Max PV input Current / Input Power27A/9000W
MPPT Range@Operating Voltage (VDC)60~450
PV Start-up Voltage (VDC)80
Max PV Open Circuit Voltage (VDC)500
Max PV Charge Current (A)120
Max AC Charge Current (A)120
Max. Charge Current (PV+ AC)(A)120
Battery
Normal Voltage (VDC)48
Battery TypeLithium / Lead-acid
General Data
HMILCD
InterfaceRS485/RS232/CAN /CT/ Meter(Optional)
MonitoringWFi (Optional)
Ingress ProtectionIP20
Operating Temperature-10 C~60 C
Relative Humidity5% - 95% (Non-condensing)
Storage Temperature-15C~60 C
Dimensions (WH*D328*112*490mm (without bracket)
Max. Operating Altitude4000m (Derating above 2000m)

Company Profile




No comment

Previous : HS-PV9000-24 S Next : HS-PV8500-48
